Leica M320 F12 Microscope

The Leica M320 F12 combines premium quality Leica optics with cutting-edge LED illumination and high-definition imaging technologies, all in an affordable and compact package designed specifically for ENT surgeons. This microscope offers crystal-clear visualization and ease of maneuverability, making it an industry benchmark for routine ENT applications. With its sleek, hygienic design and integrated features, the M320 F12 enhances workflow efficiency while providing the visual clarity needed for precise diagnostics and surgeries.

Key Features and Benefits

• Premium Apochromatic Optics: Delivers crisp, bright images with amazing depth of field, allowing surgeons to see more detail than ever before.
• Integrated Dual-LED Illumination: Provides two light paths for shadow-free illumination, especially in deep cavities. The daylight-temperature LEDs offer high-fidelity color and have a 60,000-hour lifespan, reducing maintenance costs.
• High-Definition Imaging: Optional integrated HD video and photo camera (1080p video, 3MP still photos) allows for easy sharing and documentation of surgical procedures on an internal SD memory card.
• Ergonomic Design: Customizable to individual preferences with a wide range of binocular tubes, including straight and inclinable 0-180° options, and a choice of single or dual handles.
• Hygienic and Streamlined: Features a virtually jointless design with internally routed cables for easy cleaning. Surfaces are protected with AgProtect™, an antimicrobial nano-silver coating that reduces pathogens.

Specifications

• Magnification: Manual APOchromatic 5-step magnification changer (6.4x, 10x, 16x, 25x, 40x).
• Focusing: Objectives with fixed focal lengths (f=100mm to f=400mm) and fine focusing lenses (f=200, 250, 300 mm).
• Illumination: 2 LEDs with 60,000-hour service life; UV and IR-free.
• Binocular Tubes: Options include straight binocular tube and 0-180° inclinable binocular tube.
• Eyepieces: 10x21B, 12.5x17B, 8.33x22B, 10x21B with reticule.
• Filter: Built-in orange filter (OG530) for illumination and observation.
• Documentation: Optional integrated HD camera (720p/1080p video, 3MP photo), SD card storage (up to 32GB), and IR remote control.
• Stand Options: Floor stand (FP12), Wall mount (W12), Ceiling mount (C12).

Clinical Applications

The Leica M320 F12 is engineered for a variety of ENT procedures:

• Otology: Provides deep cavity illumination and high magnification for ear examinations and surgeries.
• Rhinology: Offers clear visualization for nasal procedures.
• Laryngology: Enhances detail recognition for throat and vocal cord inspections.

Why Choose the Leica M320 F12?

The Leica M320 F12 is designed to meet the demands of the modern ENT practice. Its “hands-on” design philosophy ensures functional elegance and ease of use, while the integration of LED technology significantly reduces the cost of ownership by eliminating the need for bulb and fiber optic cable replacements. Whether for routine examinations or complex surgeries, the M320 F12 provides the reliability and visual quality that surgeons trust.

Prescott’s Surgical Microscopes Support and Service

At Prescott’s, we are dedicated to supporting your surgical equipment needs. Our team of expert technicians offers comprehensive installation, calibration, and repair services for the Leica M320 F12. Contact Prescott’s Surgical Microscopes today to learn more or request a quote.
