Leica M525 F40 / M520 F40 Microscope

The Leica M525 F40 is a premium multidisciplinary surgical microscope engineered to meet the rigorous demands of neurosurgery, spine, otolaryngology, and reconstructive procedures. Combining Leica’s high-resolution OptiChrome™ optics with the compact and stable F40 floor stand, this system provides surgeons with an expanded working distance, greater depth of focus, and superior illumination. Its refined design allows for effortless maneuverability and seamless integration with advanced neuronavigation and imaging systems, offering an exceptional balance of performance and value for high-stakes microsurgery.

Key Features and Benefits

• OptiChrome™ Premium Optics: Integrates advanced glass and coatings to deliver a 30% increase in depth of focus and light intensity, providing higher contrast and crisper images for delicate procedures.
• Motorized Multifocal Positioning: Features a motorized Varioskop objective lens providing an extended working distance from 207mm to 470mm, allowing for precise focus adjustments without the need to swap lenses.
• High-Intensity Illumination: Powered by a 300W Xenon light source for daylight-quality brightness, with a quick-change 150W Halogen backup that activates automatically in less than one second.
• ISUS Intelligent Setup: The Intelligent Set Up System (ISUS) stores preferred motorized speeds, illumination levels, and footswitch settings for up to 8 different users.
• Compact and Stable Stand: The F40 stand features a small 25″ x 25″ footprint and an extra-long swing arm with six electromagnetic brakes for optimal reach and steady positioning even in cramped operating rooms.
• Advanced Integration: Compatible with the Leica DI C500 dual imaging module, allowing surgeons to view high-resolution CT, MRI, or endoscopic data directly through the eyepieces.

Specifications

• Magnification: Motorized 6:1 zoom; range of 1.2x to 12.8x (with 10x eyepieces).
• Working Distance: Motorized multifocal lens variable from 207mm to 470mm.
• Binoculars: Interchangeable options including 0°–180° or 30°–150° variable angle tubes.
• Field of View: 16.5mm to 180mm diameter.
• Stand Range: Maximum reach of 1440mm with a transport height of 1950mm.
• Power Requirements: Universal 100–230 V, 50/60 Hz.
• Weight: Approximately 280kg (617 lbs) fully configured.

Prescott’s Support and Service

Prescott’s Surgical Microscopes offers the Leica M525 F40 fully refurbished and calibrated by our expert optical technicians. We provide comprehensive maintenance contracts, 24/7 field service, and a dedicated repair/exchange program to ensure your surgical suite operates with zero downtime. Contact Prescott’s Surgical Microscopes today for a professional quote tailored to your facility’s neuro, spine, or ENT requirements.
